iC-PNE Series Webinar video with Chinese subtitles
December 20th, 2023
On October 10th iC-Haus held a webinar about our new product iC-PNE Series.
The webinar video is now available online for everyone, with Chinese subtitles. Key takeaways from the webinar:
- Understand the differences between Vernier scales and other position encoding principles
- Learn about the latest optical phased arrays for precision absolute encoders
- See a live demonstration of the new iC-PNE system
Click here to see the webinar and all the other iC-Haus videos.
October 27th, 2023
In November 2023, iC-Haus will participate in the SPS 2023 trade show in Nuremberg, Germany:
SPS smart production solutions
Location: Exhibition Centre Nuremberg, Nuremberg, Germany
Date: November 14th - 16th, 2023
iC-Haus Booth: Hall 4A Booth 146
Please visit our booth during the trade shows to learn more about our new products, as well as talk to our engineers about your applications problems and needs!
Shanghai Tradeshow in July 2023
June 15th, 2023
iC-Haus will participate in the electronica China tradeshow in Shanghai:
electronica China
Location: National Exhibition and Convention Center (Shanghai)
Date: July 11th - 13th, 2023
iC-Haus Booth: hall 7.2, booth C132
Please visit our booth during the tradeshow to learn more about our new products, as well as talk to our engineers about your applications problems and needs!
Laser Tools Webinar video with Chinese subtitles
June 7th, 2023
On May 23rd iC-Haus held a webinar about Laser Tools.
The webinar video is now available online for everyone, with Chinese subtitles. Key takeaways from the webinar:
- Measuring of nanosecond light pulses
- Supply of short (ns) and high-frequency (MHz) electric pulses to driver iCs
- Simple access of full chip potential through optimized evaluation boards
- Learn about common errors when measuring nanosecond laser pulses and how to avoid them
Click here to see the webinar and all the other iC-Haus videos.
April 19th, 2023
On April 18th iC-Haus held our first webinar completely in Chinese, presenting our new magnetic encoder chip iC-TW39: Next Generation High-Resolution Magnetic Angle Sensing Utilizing TMR Technology.
The webinar video is now available online for everyone. The webinar is divided in 3 parts:
- Theory explanation
- Experimental demonstration
- Q&A
Click here to see the webinar and all the other iC-Haus videos.
World of Mini Encoders Webinar video with Chinese subtitles
March 28th, 2023
On February 28th iC-Haus held a webinar about the World of Mini Encoders.
The webinar video is now available online for everyone, now with Chinese subtitles. Key takeaways from the webinar:
- Overview of the “World of Mini Encoder iCs”
- Tips and tricks for application-specific selection of encoder ICs
- Adjustment and installation in selected application examples
- Watch a live demo
Click here to see the webinar and all the other iC-Haus videos.
Invitation to our first Chinese Webinar
March 9th, 2023
iC-Haus kindly invites you to our first webinar fully in Chinese.
On April 18th we will hold a live webinar in Chinese, introducing our new high-resolution magnetic encoder product iC-TW39.
Based on the theoretical concepts, the superiority of the iC-TW39 in terms of accuracy, alignment and calibration will be presented with a practical perspective, which allows you to sense the innovative capabilities that iC-Haus has been working on.
There will be three sessions during the webinar: "Theory explanation", "Experimental Demonstration" and "Q&A". We truly hope that there will be an interactive exchange between us.
Click here to register in advance for the webinar.
Click here for more information about iC-TW39.
iC-TW39 Webinar video with Chinese subtitles
October 28th, 2022
On March 29th iC-Haus held a webinar about our iC-TW39 high resolution magnetic encoder solution.
The webinar video is now available online for everyone, now with Chinese subtitles. Key takeaways from the webinar:
- Get to know the differences between end-of-shaft XMR and Hall angle sensors
- Get motivated why using TMR sensors when concerning ultimate precision
- Get introduced to the new iC-TW39 angle sensor and its extensive features
- View a live demonstration of iC-TW39 performance
Click here to see the webinar and all the other iC-Haus videos.
October 9th, 2022
On October 6th iC-Haus held a webinar about our iC-HS and DToF distance measurement.
The webinar video is now available online for everyone. Key takeaways from the webinar:
- Design choices for a practical direct ToF setup
- Direct ToF key components overview
- Mastering the challenges of a direct ToF application
Click here to see the webinar and all the other iC-Haus videos.
April 6th, 2022
On April 5th iC-Haus held a webinar about our iC-BL solution for BiSS Line.
The webinar video is now available online for everyone. Key takeaways from the webinar:
- Learn about smart BiSS Line features designed for motor feedback, robotics, and robust controller links.
- Get to know the bridge component iC-BL, which eases BiSS Line implementations into any device and platform.
- Watch a live demo of BiSS Line using iC-BL evaluation components.
Click here to see the webinar and all the other iC-Haus videos.
March 31st, 2022
On March 29th iC-Haus held a webinar about our iC-TW39 high resolution magnetic encoder solution.
The webinar video is now available online for everyone. Key takeaways from the webinar:
- Get to know the differences between end-of-shaft XMR and Hall angle sensors
- Get motivated why using TMR sensors when concerning ultimate precision
- Get introduced to the new iC-TW39 angle sensor and its extensive features
- View a live demonstration of iC-TW39 performance
Click here to see the webinar and all the other iC-Haus videos.
iC-Haus with Ultra-Short Pulse Laser Drivers for Fluorescence Analysis
February 10th, 2022
Tuberculosis is still a severe disease: in 2020, about 10 million cases were registered worldwide, and about 1.5 million people died as a result of the disease, mostly in developing countries.
The German Federal Ministry of Education and Research (BMBF) is funding a project called FluoResYst, with the purpose of developing an innovative rapid detection system for multidrug resistance in tuberculosis infections. This system will combine fast fluorescence effects with fast detectors.
iC-Haus is participating in this project by developing a new and optimized ultra-fast Laser Driver. The solution will be a customized driver IC meeting the application's specific requirements, based on iC-Haus' leading edge laser drivers technology.
For more information about this project you can check our Wechat account.
November 29th, 2021
On November 25th the BiSS Association held a webinar about the BiSS platform.
The open-source BiSS Interface has been implemented by almost 600 licensees all over the world. Recently, it has been extended by the BiSS Safety profile definition for safety-critical applications and its one-cable technology BiSS Line.
The webinar video is now available online for everyone. The contents of the webinar:
- Introduction
- The BiSS Interface Platform
- BiSS Interface
- BiSS Safety
- BiSS Line - One Cable Technology
- Q&A Session
Click here to see the webinar and all the other videos.
iC-RZ/iC-RB Series Webinar video
November 10th, 2021
On November 9th iC-Haus held a webinar about our iC-RZ / iC-RB Encoder Chips for Safety Applications.
The webinar video is now available online for everyone. Key Takeaways from the webinar:
- Get to know more about the iC-RZ Series and the new iC-RB Series
- Learn how to combine iC-RZ with the iC-MR3 interpolator for high-resolution safety encoders
- BiSS Safety
- View a live demo of a safety encoder application
Click here to see the webinar and all the other iC-Haus videos.
October 9th, 2021
On October 5th iC-Haus held a webinar about our off-axis high-resolution magnetic absolute encoder iC-MU Series.
The webinar video is now available online for everyone. Key Takeaways from the webinar:
- Introduction of the iC-MU Series
- Live Demo: from mechanical setup to a standalone encoder solution
- Special functions
- Tips & tricks for troubleshooting
Click here to see the webinar and all the other iC-Haus videos.
September 16th, 2021
iC-Haus China just inaugurated its Wechat account, keeping us even closer to our valued customers. Our Wechat account will be periodically updated with iC-Haus products news, technical information, videos, etc.
Feel free to use Wechat to scan the QR code on the left to follow the iC-Haus China account!
iC-Haus representative office in Shenzhen
July 7th, 2021
iC-Haus is coming closer to its valued partners and customers in China with the opening of the representative office "iC-Haus China" as support center in Shenzhen.
This new office is managed by iC-Haus FAE Eduardo Cheng and will soon be expanded by local engineers and experts from iC-Haus Germany in order to assist the design-in of our iCs in customer applications, especially for automation, robotics, and optics.
iC-Haus China will support customers and its established sales channels in China by personal visits, video meetings with the engineers, and at the trade shows.
iC-Haus China representative office PR
May 21st, 2021
From March to April 2021 iC-Haus conducted three online webinars showing hands-on usage of our latest products and technologies. We have uploaded the webinar videos, so everyone interested can watch them at a convenient time. The three webinars topics:
- Reflective Absolute Encoders for Precise Linear and Hollow Shaft Position Measurements
- Battery Buffered Magnetic Absolute Encoders from Gear Wheels or Incremental Scales
- Taking Time of Flight (ToF) Measuring to a New Level with Ultra Short Laser Pulses
Click here to see all the iC-Haus Videos.
AEC Q100 qualified magnetic encoder iCs
March 19th, 2021
The iC-MU200 and iC-MHL200 magnetic encoder ICs from iC-Haus are now qualified according to AEC Q100 (Grade 1) - for use in automotive applications in the temperature range from –40 to +125 °C. The ICs are suitable for high-precision hollow shaft and off-axis rotary measurements and can be used, among other things, in electrically commutated motors, for measuring steering angles, in lidar applications or for general angle detection applications.
The iC-MU200 is suitable for applications that require absolute position information right after switching on the encoder system. This is achieved by simultaneously scanning two magnetic tracks according to the Nonius principle. The absolute positon is provided with typically 19-bit resolution. For incremental applications, the Hall encoder iC-MHL200 is well suited. Both encoder ICs are optimized for pole widths of 2 mm.
The available interfaces SPI (iC-MU200), BiSS C, SSI, A/B/Z (FlexCount®) and U/V/W offer maximum flexibility.
Shanghai Tradeshow in April 2021
February 23rd, 2021
iC-Haus will participate in the electronica China 2021 tradeshow in Shanghai:
electronica China 2021
International Trade Fair for Electronic Components, Systems and Applications
Location: Shanghai New International Expo Centre, China
Date: April 14th - 16th, 2021
iC-Haus Booth: hall N2, booth 2507
Please visit our booth during the tradeshow to learn more about our new products, as well as talk to our engineers about your applications problems and needs!
iC-Haus highlight products presentation videos
November 23rd, 2020
We invite you to discover our latest products and technologies in online video presentations:
- New reflective encoder iCs for incremental and absolute encoder applications
- Laser diode drivers for ns-pulses and CW operation
- System-on-Chip Sin/Cos interpolation iCs
- High-resolution CMOS line scanner
Feel free to contact our application and design engineers who are available to inform you about ongoing developments, news, series products, and our capability for customized integrated circuits.
Click here to see all the iC-Haus Videos.
Shanghai Tradeshow in July 2020
January 13th, 2020
iC-Haus will participate in the electronica China 2020 tradeshow in Shanghai:
electronica China 2020
International Trade Fair for Electronic Components, Systems and Applications
Location: National Exhibition & Convention Center (Shanghai) (new location)
Date: July 3rd - 5th, 2020 (new date)
iC-Haus Booth: 5.2B 316
Please visit our booth during the tradeshow to learn more about our new products, as well as talk to our engineers about your applications problems and needs!
Note: new date, location and booth number!
October 11th, 2019
In November 2019, iC-Haus will participate in the SPS 2019 trade show in Nuremberg, Germany:
SPS smart production solutions
Location: Exhibition Centre Nuremberg, Nuremberg, Germany
Date: November 26th - 28th, 2019
iC-Haus Booth: Hall 4A Booth 136
Please visit our booth during the trade shows to learn more about our new products, as well as talk to our engineers about your applications problems and needs!
October 10th, 2019
Just in time for its 35th anniversary, iC-Haus is expanding its production capacity in Bodenheim, Germany, with its fifth building section.
Development, production, and qualification as well as testing and sales are now concentrated at the company’s headquarter on 18,000 m2 (200,000 ft2). Since its founding in 1984, the name iC-Haus stands for application and customer-specific integrated circuits, which are acquired and offered by a worldwide network of iC-Haus.
Shanghai Tradeshow in March 2019
January 28th, 2019
iC-Haus will participate in the electronica China 2019 tradeshow in Shanghai:
electronica China 2019
International Trade Fair for Electronic Components, Systems and Applications
Location: Shanghai New International Expo Centre, China
Date: March 20th - 22nd, 2019
iC-Haus Booth: Hall E4, Booth 4224
Please visit our booth during the tradeshow to learn more about our new products, as well as talk to our engineers about your applications problems and needs!
German Trade Shows in November
October 10th, 2018
In November 2018, iC-Haus will participate in 2 trade shows in Germany: electronica 2018 (Munich) and SPS/IPC/Drives 2018 (Nuremberg):
electronica 2018
Location: Messe München, Munich, Germany
Date: November 13th - 16th, 2018
iC-Haus Booth: Hall B5 Booth 412
SPS/IPC/Drives 2018
Electric Automation Systems and Components International Exhibition and Conference
Location: Exhibition Centre Nuremberg, Nuremberg, Germany
Date: November 27th - 29th, 2018
iC-Haus Booth: Hall 4A Booth 155
Please visit our booth during the trade shows to learn more about our new products, as well as talk to our engineers about your applications problems and needs!
Shanghai Tradeshow in March 2018
January 19th, 2018
iC-Haus will participate in the electronica China 2018 tradeshow in Shanghai:
electronica China 2018
International Trade Fair for Electronic Components, Systems and Applications
Location: Shanghai New International Expo Centre, China
Date: March 14th - 16th, 2018
iC-Haus Booth: Hall E4, Booth 4314
Please visit our booth during the tradeshow to learn more about our new products, as well as talk to our engineers about your applications problems and needs!
June 27th, 2017
The whitepaper entitled "Encoder Blue goes reflective" is now available in chinese.
Traditional optical encoders rely on transmissive optics, which is a mature and well-known technology for encoders. However, it also has its own inherent drawbacks, limiting its application in certain scenarios. In order to better suit different applications and their specific requirements, new encoder technologies are constantly being developed and implemented.
An alternative technology for encoders is based on reflective optics, which tries to improve on the features where transmissive encoders tend to fall short. The reflective optical encoder with blue light is one example of such a new technology, and is being released by iC-Haus as the iC-PR and iC-PX Series integrated circuits.
This article details the features and advantages of this new approach.
The article in chinese can be downloaded here.
Other whitepapers and different materials are listed in our downloads page.
List of iC-Haus Optical Encoder iCs.
Shanghai Tradeshow in March 2017
February 6th, 2017
iC-Haus will participate in the electronica China 2017 tradeshow in Shanghai:
electronica China 2017
International Trade Fair for Electronic Components, Systems and Applications
Location: Shanghai New International Expo Centre, China
Date: March 14th - 16th, 2017
iC-Haus Booth: Hall E4, Booth 4326
Please visit our booth during the tradeshow to learn more about our new products, as well as talk to our engineers about your applications problems and needs!
German Trade Shows in November
October 3rd, 2016
In November 2016, iC-Haus will participate in 2 trade shows in Germany: electronica 2016 (Munich) and SPS/IPC/Drives 2016 (Nuremberg):
electronica 2016
27th International Trade Fair for Electronic Components, Systems and Applications
Location: Messe München, Munich, Germany
Date: November 8th - 11th, 2016
iC-Haus Booth: Hall A5 Booth 338
SPS/IPC/Drives 2016
Electric Automation Systems and Components International Exhibition and Conference
Location: Exhibition Centre Nuremberg, Nuremberg, Germany
Date: November 22th - 24th, 2016
iC-Haus Booth: Hall 6 Booth 440
Please visit our booth during the trade shows to learn more about our new products, as well as talk to our engineers about your applications problems and needs!
July 15th, 2016
The full article entitled "Masked Poinnt-Source LEDs Optimize Sensor Illumination" is now available in chinese.
LEDs are gradually being adopted by more and more applications each year. High efficiency, simplicity and low cost are the main advantages driving the tendency to use LEDs instead of other traditional illumination sources. However, different requirements are imposed by some specific applications, in some cases not yet solved by traditional LED techniques. One of such applications is in optical sensors which provide high fidelity information for high accuracy triangulation, machine vision, etc. They require extremely homogeneus light intensity, as well as well-defined illumination geometry, characteristics still hard to achieve using traditional LED technology.
In this context, this article describes various LED technologies available, their advantages and disadvantages, and presents a new type of solution: Masked Point-Source LEDs. Its concept is explained and application examples are described.
The Masked Point-Source LED was designed by iC-Haus and it is implemented in our readily available iC-TL6 Point-Source LED product. Other variations of the Masked Point-Source LED can be easily designed according to the requirements of each application.
The article in chinese can be downloaded here.
Other whitepapers and different materials are listed in our downloads page.
May 27th, 2016
iC-TW28: 10-Bit Sin/Cos Interpolator with Auto-Calibration
iC-TW28 is the newest addition to the iC-Haus portfolio of interpolators for encoder applications. Its high integration provides a feature-rich solution, fully configurable and therefore suitable for a wide variety of applications. Up to 10-bit angle resolution is achieved, as well as these main features:
- ABZ quadrature and/or UVW commutation outputs
- Configuration per pin or SPI interface, parameters can be stored in the integrated EEPROM
- High input frequency (up to 700 kHz), low latency (typ. 1.5 µs)
- Automatic compensation of amplitude, offset and phase errors
- 10-bit angle data and 14-bit multi-cycle counter available through SPI
The small 5x5 mm QFN package integrates all features: signal conditioning, interpolation circuit, LED intensity control, RS422 output line drivers and EEPROM. The chip is operated with a single 3.3 V supply, within -40°C and +125°C. The iC-TW28 is suitable for rotary and linear encoders, and can be connected to different types of sine/cosine sensors (optical, magnetic with MR bridges, etc).
More information about iC-TW28
Shanghai Tradeshow in March 2016
February 16th, 2016
iC-Haus will participate in the electronica China 2016 tradeshow in Shanghai:
electronica China 2016
15thInternational Trade Fair for Electronic Components, Systems and Applications
Location: Shanghai New International Expo Centre, China
Date: March 15th - 17th, 2016
iC-Haus Booth: Hall E2, Booth 2336
Please visit our booth during the tradeshow to learn more about our new products, as well as talk to our engineers about your applications problems and needs!
New Product: iC-PR Series Encoder Blue®
December 20th, 2015
iC-PR: Encoder Blue® Reflective Optical Encoder iCs
Encoder Blue® goes reflective! iC-PR is a new product in the iC-Haus optical encoder iCs portfolio. Directed at applications which require flat incremental encoders, iC-PR operates using light reflection. The light source is a high quality blue LED, which is already integrated in the lensless chip package. The main features of iC-PR are:
- Relaxed assembly tolerances
- Pin-selectable output mode: analog Sin/Cos/Z signals or digital ABZ (interpolated up to 16x)
- Integrated blue LED with automatic power control
- Wide temperature range: -40°C to +105°C
The chip comes in a compact optoQFN24 package for easy handling, and do not require optical lenses. The iC-PR variants are suitable for different code disc sizes and resolutions. Due to its compact size, robustness and flexibility, iC-PR is recommended for a wide range of applications, including miniature motors and actuators, factory automation robots, consumer robots, etc.
Download the iC-PR Flyer in Chinese
October 8th, 2015
The whitepaper 7 (High-Precision Sine/Cosine Interpolation) is now available in chinese.
Interpolation is a process of increasing the resolution of signals. This process is frequently used in speed control or positioning, in order to allow motion control systems to receive high accuracy feedback information from a positioning sensor.
In this context, the whitepaper explores the concept of position signal interpolation, compares different interpolation methods and also explains how the latest solutions can be used to achieve high accuracy.
The whitepaper in chinese can be downloaded here.
Other whitepapers and different materials are listed in our downloads page.
List of iC-Haus Interpolator iCs.
German Trade Shows in November
September 28th, 2015
In November 2015, iC-Haus will participate in 2 trade shows in Germany: COMPAMED 2015 (Düsseldorf) and SPS/IPC/Drives 2015 (Nuremberg):
COMPAMED 2015
High tech solutions for medical technology
Location: Düsseldorf Fairgrounds, Düsseldorf, Germany
Date: November 16th - 19th, 2015
iC-Haus Booth: Hall 08a Booth R10
SPS/IPC/Drives 2015
Electric Automation Systems and Components International Exhibition and Conference
Location: Exhibition Centre Nuremberg, Nuremberg, Germany
Date: November 24th - 26th, 2015
iC-Haus Booth: Hall 6 Booth 440
Please visit our booth during the trade shows to learn more about our new products, as well as talk to our engineers about your applications problems and needs!
New Product: iC-PNH3348 Encoder Blue®
July 17th, 2015
iC-PNH3348: Encoder Blue® Phased Array Nonius Encoder
iC-PNH3348 is a new product in the iC-Haus optical encoder iCs portfolio. It features integrated photosensors arranged as an HD Phased Array, providing excellent signal fidelity at relaxed alignment tolerances. The photosensors are enhanced for blue light, providing better signal amplitude and contrast, with reduced noise. The main features of iC-PNH3348 are:
- Up to 24-bit singleturn resolution
- Ultra low dark currents for wide operating temperature range
- Low power consumption from 4.1 to 5.5 V supply
- Low noise amplifiers with high gain
To achieve best results and form a full Encoder Blue® solution, the iC-PNH3348 can be perfectly combined with the iC-MN (Nonius Interpolator) and iC-TL46 (blue LED), creating an absolute encoder with up to 24-bit singleturn resolution.
More information about iC-PNH3348
May 15th, 2015
iC-TW11: 10-bit Ultra Low Power Magnetic Absolute Rotary Encoder
iC-TW11 is a single-chip rotary encoder for low-power applications. It contains a SPI serial interface for configuration, sampling trigger and position data readout. When triggered, the position is acquired through the measurement of 3 Hall sensors. An automatic sleep mode keep the current consumption below 100 nA between samples. The main features of iC-TW11 are:
- 10-bit angle resolution
- 3.3V supply, I/O interface 1.8V - 3.3V
- Sampling Trigger through SPI or dedicated pin
- Automatic gain control for Hall sensors signals
- Cascadable interface
- Digital filter
The digital filter inside iC-TW11 increase the measured accuracy, but can be deactivated in order to reach even lower power consumption (average 3uA with 10 Hz sampling). Together with its space saving package (4x4mm QFN16), it's a perfect solution for compact, battery-powered devices.
More information about iC-TW11
April 10th, 2015
iC-MR: 13-bit Sin/Cos Interpolator With Controller Interfaces
iC-MR is a high-accuracy, fast and safe Sin/Cos interpolator with integrated analog signal conditioning, a low-latency Sample & Hold SAR converter, various digital interfaces, analog output driver, as well as monitoring functions for safety applications. The main features of iC-MR are:
- 13-bit Sin/Cos to digital conversion within 2 µs
- Up to 500 kHz input frequency with maximum interpolation resolution
- Input signal stabilization through LED or MR bridge current control
- Serial BiSS, SSI, SPI and 8-bit parallel MCU digital interfaces, analog 1Vpp output driver
- Multiturn interface
iC-MR also provides many safety features, like: input signal level monitoring, short-circuit/wire breakage detection, temperature sensor monitor and safe data transmission with life-counter and CRC check. The iC also contains an absolute data interface, which can be used to extend the data with multiturn values, for a maximum of 50-bit multiturn+singleturn data.
This chip can be used inside a rotary or linear encoder, providing high resolution interpolation and digital output, or as an interface module inside a controller, receiving external sine encoder signals.
February 4th, 2015
Encoder Blue: iC-Haus brings innovation for a new generation of optical encoders using blue LEDs!
Combining the availability of high-quality blue LEDs at low costs and improved techniques in the optical sensor design, the new blue LED powered encoders can provide many advantages in comparison to the traditional IR / red LED approach:
- Improved signal contrast
- Less harmonic distortion
- Less signal jitter
- Higher resolutions possible
- Improved assembly tolerances
These improvements can be achieved for both absolute and incremental encoders, using our new iC-TL46 blue LED together with our new opto encoder iCs with the HD-Phased Array technology for smaller structures which benefit largely from the shorter wavelength of the blue light.
Our iC-PT H-Series is a new released single-chip optical encoder iCs, carrying the HD-Phased Array technology, as well as a 4-fold interpolation circuit and a LED driver with automatic current control. This allows this small 5 x 5 mm² chip to deliver high resolution incremental (AB) signals, together with an index pulse (Z) and commutation signals (UVW). Using small diameter discs it is possible to achieve resolutions of 10,000 pulses per revolution with maximum rotation speed of 10,000 rpm.
Download the Encoder Blue press release
More information about Encoder Blue (iC-Haus Website in English)
January 7th, 2015
iC-Haus will participate in the electronica China 2015 tradeshow in Shanghai:
electronica China 2015
14thInternational Trade Fair for Electronic Components, Systems and Applications
Location: Shanghai New International Expo Centre, China
Date: March 17th - 19th, 2015
iC-Haus Booth: Hall E3, Booth 3226
Please visit our booth during the tradeshow to learn more about our new products, as well as talk to our engineers about your applications problems and needs!
December 30th, 2014
iC-MB4 is a BiSS interface master, compatible with encoders using BiSS or SSI interface. The complete communication protocol is controlled by iC-MB4, and the readout sensor data can be fetched by a microcontroller/DSP. Register communication and actuator communication are also integrated in a small 5x5 mm QFN28 package (TSSOP24 also available). The main features of iC-MB4 are:
- Supports BiSS-C, BiSS-B, SSI and SSI extended protocols
- Bidirectional BiSS communication (max. 8 slaves, data rates up to 10 Mbit/s)
- Interface with integrated transceivers: 2 channels (TTL or CMOS) or 1 channel (RS422 or LVDS)
- Automatic line delay compensation
- SPI or parallel interface to host (e.g. microcontroller or DSP)
The sensor data readout operation can be triggered automatically (AGS) or externally through pin or command. The CRC verification of the readout data is executed automatically by iC-MB4, with an error signaling in case of failure. The iC works with a single 3V to 5V supply, and is suitable for all applications where position acquisition and configuration of BiSS devices are needed, like multi-sensor systems, position encoder controllers, motor feedback systems, robotics, etc.
German Trade Shows in November
September 5th, 2014
iC-Haus will participate in 3 trade shows in Germany: electronica 2014 (Munich), COMPAMED 2014 (Düsseldorf) and SPS/IPC/Drives 2014 (Nuremberg):
electronica 2014
26th International Trade Fair for Electronic Components, Systems and Applications
Location: Messe München, Munich, Germany
Date: November 11th - 14th, 2014
iC-Haus Booth: Hall A5 Booth 338
COMPAMED 2014
High tech solutions for medical technology
Location: Düsseldorf Fairgrounds, Düsseldorf, Germany
Date: November 12th - 14th, 2014
iC-Haus Booth: Hall 08a Booth R10
SPS/IPC/Drives 2014
Electric Automation Systems and Components International Exhibition and Conference
Location: Exhibition Centre Nuremberg, Nuremberg, Germany
Date: November 25th - 27th, 2014
iC-Haus Booth: Hall 6 Booth 440
Please visit our booth during the trade shows to learn more about our new products, as well as talk to our engineers about your applications problems and needs!
September 3rd, 2014
iC-MHM: 14-bit Magnetic BiSS/SSI Encoder iC with Multiturn Interface.
iC-MHM is an absolute angle encoder, with a single-chip integrating Hall sensors, high resolution real-time sine-to-digital conversion, serial interface, multiturn interface as well as RS422 and LVDS transceivers, all integrated in a 5x5 mm QFN28 package. The main features of iC-MHM are:
- 14-bit sine-to-digital conversion (0.02° angular resolution per 360° revolution)
- Integrated RS422 transceivers for BiSS/SSI communication up to 10 MHz
- Analog Sin/Cos 1 Vpp differential output
- Up to 46-bit resolution (32-bit multiturn + 14-bit singleturn)
- Error signalling
iC-MHM can operate safely at 80,000 RPM with 12-bit singleturn resolution, and includes safety features like CRC proof output (up to 16-bit CRC), lifecounter and error messages in case of hall sensor errors, multiturn synchronisation problems, etc. The iC operated with 4.5 to 5.5 V power supply at a temperature range from -40 to +125 °C. The iC configuration data can be loaded from an EEPROM or through a microcontroller with SPI interface.
September 2nd, 2014
iC-PV: Battery-Buffered 40-Bit Multiturn Hall Encoder.
Developed for gearless multiturn encoders, iC-PV is a low-power Hall sensor based solution, which can be easily powered by a battery. Small and cost-effective, its low-consumption (10 µA from 3.0 to 5.5 V supply) makes it ideal as an alternative to mechanical gear multiturn solutions. The main features of iC-PV are:
- Up to 40-bit revolution counting
- Automatic switch to battery power when main power fails
- Serial interface for connection with multiturn-enabled devices (e.g.: iC-LGC, iC-MHM, iC-MN, iC-MU)
- Singleturn data input for devices without multiturn interface (e.g.: iC-LNB, iC-LNG)
- Error signalling (configuration error, magnetic field monitoring, supply voltage monitoring)
iC-PV can also operate as a low-power (battery powered) 3-bit singleturn encoder with parallel output. With a voltage supply of 3.0 to 5.5 V and operating temperature range of -40 to +125 °C, iC-PV is suitable for industrial application.
September 1st, 2014
The iC-Haus China official website is online!
This website offers information about all iC-Haus products and services, with content in English and Chinese, directed to users in China. Detailed information about the iCs, downloadable material (datasheets, flyers, product selectors, software, etc), as well as a section dedicated to the BiSS interface are available to all visitors.
If you have any suggestions or comments about the website, feel free to contact us (contact information can be found under the "Contact" link at the main menu at the top of this page). Contact information about iC-Haus authorized distributors is also available at the Contact page.
If you would like to access the official website of iC-Haus (Germany), click on the link below:
iC-Haus website (Germany, content in English only)
iC-Haus China Representative Office - Phone: +86 755 8233-3310 - E-mail: contact@ichauschina.com - Wechat: iC-Haus
