I/O iCs

iC-Haus' I/O iCs provide interfacing to industrial sensors and control systems, supporting e.g. SSI, BiSS and IO-Link.

Applications:

Industrial sensors
Control panels
PLC
Absolute position measurement
Motor feedback and drive systems
Safety relevant systems
Multisensor systems

iC-Haus I/O Circuit iCs:

iC-GD	Universal IO-Interface Key Features: Two channels, each configurable as input or output Low-side and high-side switches with up to 500 mA per channel, current limitation, current measurement, status messages, cable break detection, freewheeling diode, reverse polarity protection, optional parallel connection of both channels Output of ±10 V or 0/4...20 mA with 14-bit resolution Measurement of ±10 V, ±1 V, ±100 mV, ±10 mV, ±20 mA or 4...20 mA with 16-bit resolution Input for Pt 100, Pt 1000 temperature sensors Multi-function 32-bit counter Digital output with pulse-width modulation option Internal temperature measurement with 1 K resolution SPI interface Calibration and configuration by external EEPROM via serial interface Error message at overtemperature, overload and undervoltage Shutdown of the outputs in case of error Applications: SPS control system Data acquisition Sensor interfaces Download iC-GD Datasheet Software iC-GD (no RTE) Software iC-GD (with RTE) More information about iC-GD (iC-Haus website in English)
iC-GF	IO-Link Transceiver for IO-Link Slaves Key Features: IO-Link compliant slave transceiver Dual channel current-limited switches, configurable for high-side, low-side and push-pull operation with tristate function Configuration via pins or SPI interface Protection against reverse polarity Output current of up to 150 mA per channel The channels can be inverted for antivalent output Sensor communication request function (IO-Link wake-up) Wide supply voltage range of 9 to 30 V Sensor parametrisation via a feedback channel Error detection with hysteresis and driver shutdown for excess temperature, overload and undervoltage Switching converters and linear regulators for 3.3/5 V voltage generation Applications: IO-Link slaves and IO-Link sensor interface Digital sensors Light barriers Proximity switches Download iC-GF Flyer Download iC-GF Datasheet Download Demoboard Installation Guide iC-GF Software iC-GF (no RTE) Software iC-GF (with RTE) Package Dimensions DFN, QFN More information about iC-GF (iC-Haus website in English)
iC-GFP	IO-Link Slave Transceiver Key Features: COM3 compliant IO-Link slave transceiver Two bidirectional channels, configurable for high-side, low-side and push-pull operation Parallel connection of both channels possible Channels can be inverted for antivalent output Output current of up to 200 mA per channel Programmable current limit Line side protected against reverse polarity Configuration via SPI interface with secured data transmission Wide supply voltage range of 4.5 to 36 V Two feedback channels supporting IO-Link wake-up Switching converter and linear regulators with 5/3.3/2.5/1.8 V On-chip digital temperature sensor Status alert output with excess temperature, overload and undervoltage Driver shutdown on errors Applications: IO-Link slaves Light barriers Proximity switches Download iC-GFP Flyer (Chinese) Download iC-GFP Flyer (English) Download iC-GFP Datasheet Software iC-GFP (no RTE) Software iC-GFP (with RTE) More information about iC-GFP (iC-Haus website in English)
iC-JRX	2x4 Bidirectional 24 V High-Side Driver with μC Interface For new designs, please refer to our alternative product iC-JX. Contact iC-Haus China for assistance if required. More information about iC-JRX (iC-Haus website in English)
iC-JX	4x4 Bidirectional 24 V High-Side Driver with Load Diagnosis and μC Interface Key Features: 16 bidirectional input/output stages at 24 V Input/output mode programmable in 4-channel blocks Short-circuit-proof high-side drivers with diagnosis function 500 mA pulse and 150 mA permanent load driving capability Active flyback circuit Load diagnosis for driver current, output voltage and impedance (cable fractures, resistance and short circuits) 10-bit A/D converter for the generation of diagnosis measurement values Safety features (voltage monitor, temperature sensor with warning and shutdown features, power output enable pin) Variable digital filters for the debouncing of I/O signals Fast 8-bit parallel or serial SPI-compatible µC interface permits use in buses Logic supply from 3 V upwards Applications: Industrial 24 V applications Lamp switches with diagnostic features Inductive load driver circuits for relays and valves Download iC-JX Flyer Download iC-JX Datasheet Software iC-JX Package Dimensions MQFP More information about iC-JX (iC-Haus website in English)
iC-MD	48-Bit Quadrature Counter with RS422 Receiver and SPI/BiSS Interface Key Features: Counter resolutions: 16, 24, 32 and 48 bit Counter resolutions: 16, 24, 32 and 48 bit High count frequency of up to 40 MHz Evaluation of distance-coded reference marks Cascading/bus capable via SPI and BiSS C Interface RS422, TTL, CMOS, LVDS input signals Two actuator output signals Operation from 3.3 V to 5 V Operation modes: 1-channel ABZ inputs (TTL/RS422/LVDS), 2-channels ABZ inputs (TTL), 3-channels AB inputs (TTL) Sub-system power switch offers reverse polarity protection for the overall system Loss-of-signal indicator Applications: PLC interface to linear scales and rotary encoders Motion control Quadrature encoder interfacing and processing Download iC-MD Flyer Download iC-MD Datasheet Download Demoboard Description iC-MD Software iC-MD (no RTE) Software iC-MD (with RTE) More information about iC-MD (iC-Haus website in English)

iC-Haus BiSS interface iCs:

iC-BL	BiSS Line Interface Master/Slave with RS485 Transceiver - (new) Key Features: BiSS Line slave or master 2- and 4-wire BiSS Line interface support Full BiSS Line protocol support including Forward Error Correction (FEC) Isochronous position data measurement with low jitter On-chip RS485 line transceiver for BiSS Line point-to-point and bus structures BiSS Line to BiSS C protocol transfer Digital I/O port with CMOS drivers/receivers Sensor-sided BiSS C master interface for daisy-chaining up to 8 BiSS C slaves with data lengths up to 64 bits each Full compatibility with BiSS C and BiSS Safety SSI master interface SPI slave and SPI master interface I²C master interface Sensor supply voltage: 2.5 V, 3.3 V, or 5 V (max. 200 mA) Operation at 5 V or from 7 V to 30 V supply Operating temperature range of –40°C to +105°C Applications: One-cable technology BiSS Line master or slave implementations 2- and 4-wire sensor interfaces Motor feedback Position sensing Robotics Long distance SPI links Robust multi-sensor data communication BiSS C to BiSS Line adapter Device diagnosis and condition monitoring Download iC-BL Flyer (Chinese) Download iC-BL Flyer (English) Download iC-BLM Datasheet Download iC-BLS Datasheet Download Demoboard Description BL1D Download Demoboard Description BL3M Software BiSS Line (no RTE) Software BiSS Line (with RTE) More information about iC-BL (iC-Haus website in English)
iC-MB3	BiSS Interface Master, 1 channel/3 slaves, SPI/parallel host interface Key Features: Bidirectional BiSS communication with up to 3 slaves Supports BiSS C unidirectional, BiSS B, SSI and extended SSI Synchronous acquisition with data rates up to 10 Mbit/s BiSS B slave register operations Automatic line delay compensation Data lengths of up to 64 bit for sensor data per slave CRC verification with up to 8 bits per slave SPI or parallel interface to host e.g. microcontroller Single 3 V to 5 V supply Applications: BiSS B, BiSS C unidirectional, SSI sensor communication master Device communication in multi-sensor sytems Position acquisition with encoders Drives and motor-feedback systems Device iC-MB3 is capable for BiSS B, BiSS C unidirectional and SSI sensor communication but is not recommended for new designs that require BiSS C register communication. iC-MB3 TSSOP24 requires for BiSS C register communication protocol processing support by the host. For new designs with BiSS C register communication, please refer to iC-MB4. Download iC-MB3 Datasheet More information about iC-MB3 (iC-Haus website in English)
iC-MB4	BiSS Interface Master, 2 channel, 8 slaves, RS-422 transceiver, dual SPI Key Features: Bidirectional BiSS communication with up to 8 slaves Supports BiSS C, BiSS B, SSI and extended SSI Synchronous acquisition with data rates up to 10 Mbit/s Configurable interface with TTL, CMOS, RS422 or LVDS Slave register operations during cyclic data transfers Automatic line delay compensation Data lengths of up to 64 bit for sensor data per slave CRC verification with up to 16 bits per slave 64 bytes memory for bidirectional register access SPI or parallel interface to host e.g. microcontroller Single 3 V to 5 V supply Applications: Device communication in multi-sensor sytems Position acquisition with encoders Drives and motor-feedback systems Download iC-MB4 Flyer Download iC-MB4 Datasheet Download Demoboard Description iC-MB4 Software iC-MB4 (no RTE) Software iC-MB4 (with RTE) BiSS-C Protocol Description More information about iC-MB4 (iC-Haus website in English)
iC-MCB	SPI-to-BiSS bridge with RS-422 transceiver Key Features: BiSS Interface slave Full BiSS protocol support Two data channel configurable Three slave ID occupiable Single cycle data buffer of 64 byte organized in multiple banks for simultaneous access Built-in control communication RS422 line driver/receiver for BiSS/SSI point-to-point network BiSS bus structure capable SPI slave interface for sensor data provided by microcontroller BiSS safety related features (16 bit CRC + CRC start value) BiSS timeout: adaptive, 2 μs, 20 μs SSI protocol support Operation from 3.0 V to 5.5V Operating temperature range of -40°C to +125°C Space-saving 16-pin QFN package Applications: BiSS slave implementation Multiple sensor devices Encoder Torque sensor Inclinometer Acceleration sensor Safety light curtain BiSS diagnosis extension Condition monitoring extension Download iC-MCB Flyer (Chinese) Download iC-MCB Flyer (English) Download iC-MCB Datasheet Download Demoboard Description iC-MCB More information about iC-MCB (iC-Haus website in English)
iC-MCW	BiSS Watchdog for RS422 with SPI Key Features: Acquisition of BiSS Single Cycle Data Acquisition of BiSS Control Data Monitoring of BiSS communication status Error diagnostics for debugging Pin for simple error indication Auto compensation of line delay and conversion times Internal 14-bit BiSS frame counter Built-In RS422 receiver for direct BiSS interfacing Support of BiSS data transfer rates of up to 10 MBit/s Serial controller communication via SPI™ slave interface Support of interrupt-output Built-In system and high speed sample clock generation 3.3 to 5 V supply (+/-10%) Operational temperature -40 to +125 °C Applications: BiSS communication monitoring BiSS Safety extension of BiSS standard drives Download iC-MCW Flyer (Chinese) Download iC-MCW Flyer (English) Download iC-MCW Datasheet Download Demoboard Description iC-MCW More information about iC-MCW (iC-Haus website in English)
