Inductive Encoder iCs
Inductive encoders are robust solutions, suitable for applications where position measurement is necessary in a harsh environment. The Inductive Encoder iCs can be connected directly to the coils in an inductive encoder.
The iCs include a coil driver to generate an excitation current, and also integrate the signal processing to demodulate and condition the receiver coil signals from two independent channels, making it suitable for high resolution absolute position sensing.
Applications:
- Robust absolute position sensors
- Drive speed and torque control
- Brushless motor commutation
- Robots, AGV, vending machines
iC-Haus Inductive Encoder iCs:
iC-GI22
|
Dual Channel Inductive Signal Demodulator
Key Features:
- Adjustable transmitter with coil driver (2-5 MHz, up to 20 mA)
- Two independent receiver channels with demodulation and line driver (1 Vdiff @ 100 Ω)
- High level output with selectable center voltage
- Adjustable coarse (x1...10) and fine gain (x1...20)
- Precision offset correction (via 11 bits up to 200 mV)
- Automatic gain control (per channel)
- Sin/cos interpolation with 8-bit resolution (1 channel)
- Angle output via SSI with error and warning
- I2C multi-master for self-configuration from external EEPROM
- I2C slave interface to the system (MCU)
- Operation monitoring with alarm masking: signal loss, I/O short circuit, RAM CRC
- Signal frequency up to 50 kHz (allows for 90000 rpm minimum)
- Power supply from 3.3 V to 5 V, approx. 15 mA
- Space-saving 32-pin QFN with 5x5 mm
Applications:
- Robust absolute position sensors
- Drive speed and torque control
- Brushless motor commutation
- Robots, AGV, vending machines
